PVA TePla and Fraunhofer IISB establish Joint Lab for aluminium nitride substrates
Erlangen-based Fraunhofer IISB (Institute for Integrated Systems and Device Technology) and Wettenberg-based microwave & radio frequency plasma system maker PVA TePla AG are pooling their expertise in a Joint Lab for the production of aluminium nitride (AlN) crystals.
As a European first, this partnership enables industrially supported small-batch production of monocrystalline AlN substrates with a diameter of 2-inches for R&D purposes. This significantly improves the availability of AlN substrates in Europe, which in turn accelerates the development of AlN-based devices and systems and their transition to industrial applications.
Picture: Aluminium nitride crystal with a diameter of 2-inches – grown in the Joint Lab of Fraunhofer IISB and PVA TePla (courtesy of Jennifer Reißig/Fraunhofer IISB).
Aluminium nitride is one of the most promising materials for the next generation of high-performance electronics. As an ultrawide-bandgap (UWBG) semiconductor, AlN opens up new possibilities in photonics, power electronics, high-frequency electronics, and electronics operating under extreme conditions. To date, the shortage of high-quality, large-area and cost-effective AlN substrates has been holding back the development of AlN-based electronic systems.
“With the Joint Lab, we are laying the groundwork to ensure a reliable supply of AlN substrates from Europe, thereby opening up new prospects for the next generation of high-performance AlN devices,” says Dr Sven Besendörfer, group leader for nitride materials and responsible for AlN material development at Fraunhofer IISB. “Together with PVA TePla, we are contributing our expertise in industrial crystal growth, thereby creating the prerequisites for the transfer to concrete applications.”
Proven equipment technology meets proprietary process know-how
In the joint lab, Fraunhofer IISB is using its proprietary PVT (physical vapor transport) process technology to produce 2-inch AlN bulk crystals. In this process, AlN powder is vaporized in a crucible at temperatures well above 2000°C and deposited onto a seed crystal. PVA TePla provides PVT systems for this purpose, which are already in use worldwide for 8-inch-diameter silicon carbide (SiC) crystals and have now been specially adapted for the growth of 2-inch AlN crystals.
Due to the process expertise contributed by Fraunhofer IISB, the PVA TePla team was quickly able to produce AlN crystals of comparable quality in its own facilities. The Joint Lab focuses on the stable small-batch production of 2-inch AlN crystals. Production is now being ramped up gradually to systematically optimize process stability, reproducibility, yield and cost structures.
“With aluminium nitride, we are actively shaping the next generation of technology following SiC,” says Dr Jan Pfeiffer, vice president of R&D at PVA TePla. “Through the Joint Lab, we can directly combine our equipment expertise with the process know-how of Fraunhofer IISB, enabling us to offer market-oriented solutions to our global customers at an early stage,” he adds. “Our shared goal is to stimulate market development in the AlN sector through suitable substrates and to support companies looking to enter this field as technology partners with the right equipment and corresponding process expertise.”
Strengthening European technological sovereignty through industrial scaling
The AlN crystals produced in the Joint Lab are further processed at Fraunhofer IISB into epi-ready AlN substrates and, through Erlangen-based research & product development firm LZE GmbH, specifically transferred into industrial development and scaling processes. “For Europe’s semiconductor sovereignty, it is crucial that new key materials are not only developed but also rapidly transferred into industrial applications and scalable value creation,” says LZE’s managing director Dr Christian Forster. “With its marketplace for cutting-edge technologies, LZE GmbH provides companies and research institutions with globally unique and open access to AlN substrates. In this way, we help ensure that promising applications for high-volume industrial markets are brought to market more quickly.”
At the same time, Fraunhofer IISB is driving forward the development of 4-inch and, in the future, 6-inch AlN technology. The Joint Lab is thus laying the foundation for medium- to long-term scaling of substrate sizes. The partnership also pursues the strategic goal of pooling expertise in ultrawide-bandgap technology in Europe, reducing dependencies on key materials, and sustainably strengthening Europe’s technological sovereignty in the semiconductor sector.
